Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of electric trailer mover in China. We warmly welcome you to buy discount electric trailer mover for sale here from our factory. Quality products and reasonable price are available.
Electric Trailer Mover
CATHAYLIFT Electric Trailer Mover is designed to conquer more than just flat terrain; it is built for real-world challenges. With a proven capability to tow heavy loads on inclines of up to 5°, it ensures consistent performance on ramps and gentle slopes. This is complemented by a superior Grade Ability of 10% when unloading and 5% when loading, providing exceptional stability and control during critical operations. At its core lies a high-performance DC motor, renowned for its reliability and torque, which is powered by a large-capacity battery for extended shift operation. Durability is guaranteed with a high-strength traction hook, designed to withstand rigorous daily use.
|
Model Type |
CMT-050 |
CMT-100 |
CMT-150 |
|
Max. Traction Load |
500 kg |
1000 kg |
1500kg |
|
Traction Hook height (Adjustable) |
165/205/245mm |
200/250/290mm |
200/250/290mm |
|
Drive Motor |
DC24V/400W |
DC24V/800W |
DC36V/1200W |
|
Tyre size-Driving Wheels |
2-φ260 X 95 |
2-φ310 X 120 |
|
|
Tyre size-Loading Wheels |
2-φ75 X 32 |
2-φ100 X 32 |
|
|
Height of operating handle |
1100-1250mm |
1250-1350mm |
|
|
Battery Power |
2*12V/40Ah |
2*12V/70Ah |
3*12V/70Ah |
|
Charger |
VST224-8 24V/8A |
VST224-10 24V/10A |
VST236-15 36V/15A |
|
Tractive Speed (Unload/Load) |
6/5 Kw/h |
7/6 Kw/h |
|
|
Grade Ability (Unload/Load) |
10% / 5% |
||
Features & Advantages:
- Experience formidable towing capability with a robust drive system engineered to move loads from 500kg to 1500kg with ease. This strong power output ensures that even the heaviest loads are transported without strain.
- The system operates with remarkably low noise, significantly reducing sound pollution and creating a more comfortable and communicative work environment.
- Designed for energy saving and environmental protection, its electric motor produces zero emissions on-site, contributing to a greener footprint and lower energy costs compared to traditional fuel-powered alternatives.
- CATHAYLIFT Electric Trailer Mover is equipped with bright safety warning lights and an audible beeper. When the equipment is in motion, these alerts actively warn passers-by, ensuring construction safety and preventing accidents in busy areas.
More Details:
Real Order
Hot Tags: electric trailer mover, Electric Tuggers, Industrial Tugger, Small Tractor
