Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of hydraulic lift machine in China. We warmly welcome you to buy discount hydraulic lift machine for sale here from our factory. Quality products and reasonable price are available.
Guide rail cargo lift is a kind of lifting equipment specially used for high-altitude cargo transportation between floors. The main load ranges from 1-30 tons, and the height is 1-25 meters. It can be installed and used indoors and outdoors, with stable operation, low noise, convenient maintenance and long service life. It is a kind of mechanical equipment with a wide range of uses. It has a wide range of uses, so the performance of the equipment cannot be ignored. The performance test is an important way to detect the guide rail cargo lift. Performance tests generally include: no-load test, dynamic load test, insulation test, horizontal plane stability test, rated load test.
1. No-load test: No-load test is a necessary step to carry out rated load test and an important test to check the performance of each part of the equipment, mainly including: normal operating state; manipulation, control, interlocking, and feeding conditions; limit device; hydraulic pressure Systems and lubrication levels.
2. Dynamic load test: The dynamic load test mainly verifies the function of each mechanism of the guide rail chain elevator. The dynamic load test is carried out with 1.1 times the rated load to check the operation status of the elevator, whether the mechanism and parts are loose, damaged or abnormal. .
3. Insulation test. The purpose of the insulation test is to test the insulation performance of the electrical system of the guide rail chain lift. According to regulations, the insulation of the main circuit should be greater than 1.0MΩ, and the control circuit should be greater than or equal to 2.0MΩ.
4. Horizontal plane stability test: The stability test is an important indicator to test the stability of the platform. During the test, when the center of gravity is placed 1.25 times the rated load, it must be stable.
5. Rated load test: The purpose of the rated load test is to check the equipment under the rated load and check the various indicators of the equipment, including equipment operation, manipulation, control, interlocking, feeding, limit device, hydraulic system and lubrication, rated Working oil pressure.
