Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of hydraulic lift table cart in China. We warmly welcome you to buy discount hydraulic lift table cart for sale here from our factory. Quality products and reasonable price are available.
Model type | Capacity (kg) | Platform size(mm) | Lifting height(mm) | Weight(kg) |
BS15 | 150 | 700*450 | 265-755 | 41 |
BS25 | 250 | 830*500 | 330-910 | 78 |
BS50 | 500 | 1010*520 | 435-1000 | 112 |
BS75 | 750 | 1010*520 | 442-1000 | 112 |
BS100 | 1000 | 1010*520 | 445-950 | 130 |
BS15D | 150 | 830*500 | 435-1430 | 90 |
BS30D | 300 | 1010*520 | 435-1585 | 138 |
BS50D | 500 | 1010*520 | 440-1575 | 156 |
BS80D | 800 | 1010*520 | 470-1410 | 160 |
ES30 | 300 | 1010*520 | 450-950 | 140 |
ES50 | 500 | 1010*520 | 450-950 | 148 |
ES75 | 750 | 1010*520 | 450-950 | 154 |
ES100 | 1000 | 1010*520 | 480-950 | 169 |
ES30D | 300 | 1010*520 | 495-1600 | 183 |
ES50D | 500 | 1010*520 | 495-1618 | 198 |
ES80D | 800 | 1010*520 | 510-1460 | 208 |
ES100D | 1000 | 1010*520 | 510-1450 | 230 |
BS50LA | 500 | 1525*620 | 400-1000 | 175 |
BS50LB | 500 | 1200*800 | 370-1190 | 160 |
BS100L | 1000 | 1200*800 | 425-1225 | 163 |
ES50LA | 500 | 1525*620 | 440-1575 | 215 |
ES50LB | 500 | 1200*800 | 430-1220 | 220 |
ES100L | 1000 | 1200*800 | 430-1220 | 225 |
Features & Advantages:
● Sturdy wishbone beam composite steel support and countertop construction.
● The countertop can be directly made of stainless steel cutting panel or additionally paved with stainless steel surface sticker on the basic tabletop of the basic platform truck to achieve dust and rust prevention.
● When the foot pedal is raised, the height of the table can be raised to the required level, which is easy to operate.
● There are 20,000-directional PU wheels and two-directional PU wheels, and a braking device is provided on the steering wheel.
● Lifting-travel-lowering three functions are controlled by handle, and the lowering speed can be controlled manually.
● Equipped with overload protection valve and safety stop to protect the operator and oil pump.
● Optional: Rotary switch or pull switch / chrome armrest, painted armrest or folding armrest.
