Scissor Table

Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of scissor table in China. We warmly welcome you to buy discount scissor table for sale here from our factory. Quality products and reasonable price are available.

A stationary scissor lift table is a customized lift table specially designed to meet various special needs. The product has a solid structure, large bearing capacity, good lifting stability, simple and convenient installation, and maintenance; no need to set up a cargo platform steel frame, etc., it can be lifted and unloaded directly from the ground, and the platform can be placed in the pit. After the operation, the platform is level with the ground and does not occupy the ground. space does not affect the passage of the passage. The load can vary from 100 kg to 30 tons according to the lifting height and platform size, and the lifting height and platform size can be customized according to customer needs.

Please Note: If the standard models can not meet your requirements, please ask us to customize them for you.

1. Manual or electromagnetic reversing valve, reversing valve, also known as Chris valve, can be adjusted in multiple directions, changing the fluid flow direction in time, and has a disc-type structure, which is mostly used in occasions with the small flow. When working, you only need to turn the handwheel to change the flow direction of the working fluid through the valve disc. A valve that can realize the communication, cut-off, and reversing of hydraulic oil flow, as well as pressure unloading and sequential action control.

2. Overflow valve, which plays a role of safety protection in the system. When the system pressure exceeds the specified value, the safety valve will be opened to discharge part of the gas in the system into the atmosphere, so that the system pressure will not exceed the allowable value, so as to ensure that the system will not cause accidents due to excessive pressure. Pay attention to regular inspection and cleaning during use, and take reasonable measures to ensure the safety of the safety valve.

3. Throttle valve is a valve that controls fluid flow by changing the throttle section or throttle length. It is generally only used in occasions where the load changes little or the speed stability is not high. When the throttle valve has deposits, the engine will stall or the machine will not start, and the movement will be slow and the speed will increase suddenly, which will seriously affect the safety of high-altitude operations.

4. Balance valve, a valve with special functions. Its special feature lies in the difference between the use function and the place. In some industries, because the flowing material has a large pressure difference or flow difference in various parts of the pipeline or container, in order to reduce or balance the difference, valves are installed between the corresponding pipelines or containers to Adjust the relative balance of pressure on both sides, or achieve the balance of flow through the method of shunting.
