Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of wheelchair lift with closed cabin in China. We warmly welcome you to buy discount wheelchair lift with closed cabin for sale here from our factory. Quality products and reasonable price are available.
CATHAYLIFT's Wheelchair Lift With Closed Cabin is a cutting-edge solution designed to provide accessibility and convenience for home use. This lift brings forth several distinct features and advantages, making it an ideal addition to residential properties. The CATHAYLIFT Wheelchair Lift With Closed Cabin is a robust, safe, and user-friendly solution designed to enhance accessibility in residential settings. Its minimal installation requirements, safety features, space-saving design, and silent operation make it an excellent choice for accommodating the mobility needs of individuals while maximizing comfort and convenience.
|
Model Type |
HL10 |
HL15 |
HL20 |
HL25 |
HL30 |
HL35 |
HL40 |
HL50 |
HL60 |
|
Max. Platform Height |
1000mm |
1500mm |
2000mm |
2500mm |
3000mm |
3500mm |
4000mm |
5000mm |
6000mm |
|
Load Capacity |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
|
N.W/G.W(kg) |
350/450 |
450/550 |
550/700 |
700/850 |
780/900 |
850/1000 |
880/1050 |
1000/1200 |
1100/1300 |
|
Machine Size(mm) |
2000*1430*1300 |
2500*1430*1300 |
3000*1430*1000 |
3500*1430*1000 |
4000*1430*1000 |
4600*1430*1000 |
5100*1430*1000 |
6100*1430*1000 |
7100*1430*1000 |
|
Platform size |
1430*1000mm skid proof checkered steel |
||||||||
|
Working Condition |
Both indoors and outdoors -20°~70°C |
||||||||
|
Entrance-Exit Way |
It's customized 90°or 180° |
||||||||
|
Installation |
No pit installing,easy to install and remove |
||||||||
|
Switches |
1.One control panel on the platform |
||||||||
Product Details
Key Features And Advantages:
●Minimal Civil Structure Requirements:
CATHAYLIFT's hydraulic elevator requires no machine room, significantly lowering the installation complexity.
It only needs one load-bearing wall, and the bottom pit depth can be as minimal as 60mm, making it highly adaptable to various building structures.
● Safety Assurance:
No risk of overspeeding, eliminating the dangers of top-rushing or squatting.
Robust mechanical design ensures reliable installation.
High safety factor with a backup battery enabling self-rescue for trapped individuals.
In case of failure or power outage, the internal emergency button allows the elevator to slowly descend using its own weight as hydraulic oil returns to the tank.
● Space-Saving Design:
This hydraulic lift is designed without counterweights and requires only two tracks.
This construction saves valuable building space and allows for installation in complex and tighter areas of a property.
● Silent Pump Station:
The pump station is equipped with frequency conversion and a low-noise hydraulic pump, ensuring quiet operation.
Includes an emergency lowering valve to manually lower the lift and auto-level the cabin when power is cut off.
A built-in relief valve prevents excessive pressure during upward movement and provides overload protection.
● Quiet Operation:
Equipped with a silent pump station featuring frequency conversion and a low-noise hydraulic pump.
Includes an emergency lowering valve for manual operation and automatic leveling during power cuts.
Built-in relief valve prevents excessive pressure during ascent, offering overload protection.
Real Order
