Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of hydraulic single mast aluminum lift in China. We warmly welcome you to buy discount hydraulic single mast aluminum lift for sale here from our factory. Quality products and reasonable price are available.
Hydraulic Single Mast Aluminum Lift
CATHAYLIFT's Hydraulic Single Mast Aluminum Lift prioritizes safety with a comprehensive suite of features. Outrigger self-locking mechanisms and indicator lights provide visual confirmation of stability, while an oil cylinder lock valve and leveling indicator guarantee a secure working platform. An emergency stop button, seat belt buckle, and durable construction further enhance user safety. The lift has earned numerous certifications, including CE, Rohs SGS ANSI, TUV standard EN280, and ISO9001, solidifying its commitment to quality and safety.
|
Model No. |
CUP-5H |
CUP-6H |
CUP-8H |
CUP-9H |
CUP-10H |
CUP-12H |
|
|
Max.Platform Height |
5m |
6m |
8m |
9m |
10m |
12m |
|
|
Max. Working Height |
6m |
8m |
10m |
11m |
12m |
14m |
|
|
Load Capacity |
150 kg |
136 kg |
120 kg |
||||
|
Platform Size |
0.67*0.66 m |
||||||
|
Occupants |
One person |
||||||
|
Outrigger Coverage |
1.7*1.7m |
1.6*1.6m |
1.7*1.7m |
1.9*1.7m |
2.3*1.9m |
||
|
Overall Size |
1.24*0.74*1.99 m |
1.36*0.74*1.99 m |
1.4*0.74*1.99m |
1.42*0.74*1.99m |
1.46*0.81*2.68 m |
||
|
Net Weight |
300kg |
320kg |
345kg |
365kg |
385kg |
460kg |
|
|
Motor Power |
0.75 Kw |
||||||
|
Options |
DC |
12 V |
|||||
|
DC Motor |
1.5 Kw |
||||||
|
Charger |
12V 15A |
||||||
Product Details:
The lift incorporates aluminum alloy insert-type outriggers to expand the force bearing area, ensuring a robust and stable base. These outriggers are maintenance-free, guaranteeing long-lasting performance. To safeguard delicate floors, black rubber protection pads are installed on the outriggers, preventing damage during operation.
The lift is designed for easy handling and transportation. Lifting rings and standard forklift holes are incorporated, allowing for seamless loading and unloading using machines or forklifts. This thoughtful design simplifies the logistics of moving and positioning the lift, streamlining operations.
Detail Images:
The lift is equipped with an emergency lowering valve, providing a crucial safety mechanism in the event of power failures or outages. The valve allows for controlled platform descent to the ground, ensuring user safety even under unforeseen circumstances. An overload sensor is also incorporated, preventing lift operation when the weight exceeds 1.5 times the rated capacity, mitigating potential risks.
CATHAYLIFT's commitment to user safety extends to minimizing platform vibration during operation. The lift features an ultra-wide, 200mm, high-strength aluminum alloy support column. This robust construction significantly reduces shaking compared to standard, narrower columns, creating a more stable and secure working environment for operators. This attention to detail ensures confidence and safety for users.
Application:
Packing & Shipping:
