Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of ground electric hook crane in China. We warmly welcome you to buy discount ground electric hook crane for sale here from our factory. Quality products and reasonable price are available.
CATHAY industrial electric cranes are designed for hoisting, but different working conditions have different requirements for equipment performance. In view of this feature, CATHAY's latest CRANE series is equipped with an intelligent slewing main arm system, which uses integrated positioning sensors and hydraulic locking devices to achieve accurate positioning and automatic locking of the boom within the operating range. This innovative technology not only improves material transfer efficiency, but its dual safety protection mechanism can effectively prevent accidental displacement and provide reliable hoisting protection for industrial scenarios.
|
Model Type |
CSEC-1200 |
CSEC-1200A |
CSEC-700 |
CSEC-900R |
|
Horizontal Reach |
1280+610+610mm |
1280+610+610mm |
1220+610+610mm |
1280mm+610mm+610mm |
|
Load Capacity |
1200kg |
1200kg(1280mm) |
700kg(1220mm) |
900kg(1280mm) |
|
Load Capacity (stage 1) |
600kg(1280~1890mm) |
600kg(1280~1890mm) |
400kg(1220~1830mm) |
450kg(1280~1890mm) |
|
Load Capacity (stage 2) |
300kg(1890~2500mm) |
300kg(1890~2500mm) |
200kg(1890~2440mm) |
250KG(1890~2500mm) |
|
Max Lifting Height |
3570mm |
3540mm |
3560mm |
3180mm |
|
Min Lifting Height |
960mm |
935mm |
950mm |
1410mm |
|
Retracted size(W*L*H) |
1920*760*1600mm |
1865*1490*1570mm |
2595*760*1580mm |
2000*1854*1550mm |
|
Arm Electric Rotation |
/ |
/ |
/ |
120°left/right |
Product Details
Product advantages
- Energy-saving and efficient, the operating cost is lower than that of fuel-powered models
- Wireless remote control operation improves the flexibility and convenience of operation
- Multiple safety protection devices eliminate the risk of overloading
- Compact structure, suitable for narrow spaces and complex working conditions
- Zero emissions and low noise, in line with green production standards
