Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of manual man lift for sale in China. We warmly welcome you to buy discount manual man lift for sale for sale here from our factory. Quality products and reasonable price are available.
CATHAYLIFT-CTA type towable boom lift is made of high-strength steel plate, fully telescopic working arm, built-in hydraulic drive structure, strong driving force, compact structure, good maneuverability, large operating range, stable and flexible operation; automatic leveling mechanism, With manual leveling control function, the working platform can be rotated 360° continuously, the bottom plate is made of non-slip steel plate, and the working bucket is placed at the rear, which is convenient for personnel to enter and exit, and reduces the center of gravity of the vehicle; spider-type outriggers have large span and good stability, and the outriggers are It can be independently retracted and linked, and is equipped with outrigger flashing lights, which are used to indicate the outline of the outrigger during operation and issue a light alarm signal; it is equipped with an emergency power source, which can realize emergency closing; the imported hydraulic valve adjusts the operating speed of the boom . The electronic control system can be optionally equipped with a ground wireless remote control operating system.
Notice before operation:
1. Read and understand the operating instructions for this machine and become familiar with all controls.
2. The operator must be familiar with the positions and directions of various operating handles, working and lifting interlock positions, rated load and other information before working.
3. The high-altitude maintenance vehicle is not insulated and does not provide protection against electric shock. Please keep a safe distance from the power supply and equipment. If the high-altitude vehicle touches the live power line during use, please stay away from the ground or the personnel on the high-altitude vehicle platform. Do not touch or operate the machine until the power is cut off.
4. Do not operate high-altitude vehicles when there is lightning or outdoor storms.
5. Do not use the high-altitude maintenance vehicle as a ground wire during high-altitude welding operations.
6. When the aerial maintenance vehicle arrives at the job site and moves during the operation, it must be confirmed that there is no person in the moving direction that will collide with the aerial vehicle or be in the route of the vehicle.
7. When the vehicle is lifted and lowered or the turntable is moved, it must be confirmed that there are no people and obstacles below.
8. Do not use the boom to push the machine or other objects while the aerial maintenance truck is in use.
9. Personnel working on the platform should wear safety belts and helmets and use other safety measures. Do not sit, stand or climb on the guard rails on the platform, and should stand stably on the platform floor at all times.
10. In the charging state, the high-altitude lift truck must be in a stopped state.
Model Type | CTA-10A | CTA-12A | CTA-14T | CTA-16T | CTA-18T | CTA-20T |
Version | Articulated | Articulated | Telescopic | Telescopic | Telescopic | Telescopic |
Lifting height | 10M | 12M | 14M | 16M | 18M | 20M |
Working height | 12M | 14M | 16M | 18M | 20M | 22M |
Load capacity | 200KG | |||||
Platform size | 0.9*0.7M | |||||
Working radius | 5.5M | 6.5M | 8.5M | 10.5M | 11M | 11M |
Net Weight | 1855KG | 2050KG | 2500KG | 2800KG | 3000KG | 3100KG |
Overall Size( L*W*H) | 5.2*1.7*2.1M | 6.2*1.7*2.1M | 5.6*1.7*2.1M | 5.7*1.7*2.2M | 6.5*1.8*2.3M | 5.8*1.9*2.3M |
Supporting Legs Stride Distance(Horizontal) | 3.0 M | 3.6 M | 3.6 M | 3.9 M | 3.9 M | 3.9 M |
Supporting Legs Stride Distance (Vertical) | 4.7 M | 4.7 M | 4.7 M | 4.9 M | 4.9 M | 4.9 M |
Wind Resistance Level | ≦5 | |||||
20'/40' Container Loading Quantity | 20'/1set | 20'/1set | 20'/1set | 20'/1set | 20'/1set | 20'/1set |
40'/3sets | 40'/3sets | 40'/3sets | 40'/3sets | 40'/3sets | 40'/2sets | |
Power optional | AC-electrical Power (Xi'an Motor) | |||||
Diesel Power Motor (YSD Motor) | ||||||
Gasoline Power (Honda Motor) | ||||||
DC Battery Power (Bucher Motor) | ||||||
AC+ Diesel/Gas Power (Dual Power) | ||||||
AC/Diesel/Gas+DC Power (Dual Power) | ||||||
Extra Optional | Friction wheel walking device: (Automatic Moving) | |||||
Products Details
Details Images：
Real Order：
