Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of mobile lift in China. We warmly welcome you to buy discount mobile lift for sale here from our factory. Quality products and reasonable price are available.
The maintenance of the mobile lifting platform is inevitable. Regular maintenance is beneficial to improve the service life of the lifting platform. However, it must not be careless during maintenance. Improper maintenance will cause damage to the lifting platform. How to properly maintain the hydraulic lifting platform? CATHATLIFT to tell you
1. Regularly replace the hydraulic oil of the lifting platform. The hydraulic oil used by the lifting platform is divided into winter and summer. This is a place that many users do not pay much attention to. Different hydraulic oil is not replaced according to the changes of the season, and it is often only noticed when the hydraulic cylinder of the lifting platform is abnormal. In winter, the weather is relatively cold, and the hydraulic oil of the lifting platform is easy to become viscous, so thinner hydraulic oil should be used. In summer, the weather is hotter and the temperature is relatively high, and the hydraulic oil is easy to become thin, so use a thicker one. The specific replacement cycle of the hydraulic oil depends on the local weather conditions.
2. Lubricating oil should be added regularly to maintain the lifting platform. During the use of the lifting platform, because of the relatively large load, the friction between the various components is relatively large, especially the chain and the shaft pin. Appropriate amount of lubricating oil is added before each use to ensure flexible operation. During the operation of the lifting platform, when there is a fault, it must stop working immediately, find the cause, and do not work forcibly, otherwise it will easily cause safety hazards
Model No. | Loading Capacity (kg) | Lifting Height (m) | Platform Size (m) | Overall size | Lifting Time(s) | Voltage | Motor | Wheels(φ) | Net Weight (kg) |
CLH0406 | 450 | 6 | 1.85*0.88 | 1.95*1.08*1.1 | 55 | AC380 | 1.5 | 200 PU | 800 |
CLH0407 | 450 | 7.5 | 1.8*1.0 | 1.95*1.2*1.54 | 60 | AC380 | 1.5 | 400-8 Rubber | 1000 |
CLH0409 | 450 | 9 | 1.8*1.0 | 1.95*1.2*1.68 | 70 | AC380 | 1.5 | 400-8 Rubber | 1200 |
CLH0411 | 450 | 11 | 2.1*1.15 | 2.25*1.35*1.7 | 80 | AC380 | 2.2 | 500-8 Rubber | 1580 |
CLH0412 | 450 | 12 | 2.45*1.35 | 2.5*1.55*1.88 | 125 | AC380 | 3 | 500-8 Rubber | 2450 |
CLH0414 | 450 | 14 | 2.45*1.35 | 2.5*1.55*2.0 | 165 | AC380 | 3 | 500-8 Rubber | 2650 |
CLH1006 | 1000 | 6 | 1.8*1.0 | 1.95*1.2*1.45 | 60 | AC380 | 2.2 | 500-8 Rubber | 1100 |
CLH1009 | 1000 | 9 | 1.8*1.25 | 1.95*1.45*1.75 | 100 | AC380 | 3 | 500-8 Rubber | 1510 |
CLH1012 | 1000 | 12 | 2.45*1.35 | 2.5*1.55*1.88 | 135 | AC380 | 4 | 500-8 Rubber | 2700 |
CLH0316 | 300 | 16 | 2.75*1.5 | 2.85*1.75*2.1 | 173 | AC380 | 3 | 500-8 Rubber | 3200 |
Products Details
Advantages:
1. The CATHATLIFT lifting platform is equipped with an anti-fall safety protector to prevent the pipeline from bursting, which can effectively reduce the situation that the pipeline bursts and hits people.
2. The handle for emergency descent is set, which solves the problem of being unable to descend due to a power failure during use.
3. The mobile hydraulic lifting platform is equipped with a hydraulic protection system. The lifting platform is made of high-strength manganese steel moment, and the strength is very high and strong.
4. The finely ground hydraulic cylinder body and imported seals are used, which can ensure the good sealing performance of the cylinder.
5. The lifting platform is made of base + arm frame + worktable. When the base is used, high-strength steel plates are welded.
6. The lifting platform can be equipped with manual lifting, which can be used during power outages and places without electricity, and a telescopic platform can be added, which can be extended when it is not enough to improve work efficiency.
Real Order:
