Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of wheelchair lift for disabled and old people in China. We warmly welcome you to buy discount wheelchair lift for disabled and old people for sale here from our factory. Quality products and reasonable price are available.
Wheelchair Lift for Disabled And Old People
The CATHAYLIFT Wheelchair Lift is a robust, safe, and space-saving solution tailored to enhance the mobility and independence of the elderly and disabled. With advanced safety features and a user-friendly design, it represents the pinnacle of accessibility technology. Choose CATHAYLIFT for reliable, quiet, and efficient mobility solutions.
|
Model Type |
HL10 |
HL15 |
HL20 |
HL25 |
HL30 |
HL35 |
HL40 |
HL50 |
HL60 |
|
Max. Platform Height |
1000mm |
1500mm |
2000mm |
2500mm |
3000mm |
3500mm |
4000mm |
5000mm |
6000mm |
|
Load Capacity |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
|
N.W/G.W(kg) |
350/450 |
450/550 |
550/700 |
700/850 |
780/900 |
850/1000 |
880/1050 |
1000/1200 |
1100/1300 |
|
Machine Size(mm) |
2000*1430*1300 |
2500*1430*1300 |
3000*1430*1000 |
3500*1430*1000 |
4000*1430*1000 |
4600*1430*1000 |
5100*1430*1000 |
6100*1430*1000 |
7100*1430*1000 |
|
Platform size |
1430*1000mm skid proof checkered steel |
||||||||
|
Working Condition |
Both indoors and outdoors -20°~70°C |
||||||||
|
Entrance-Exit Way |
It's customized 90°or 180° |
||||||||
|
Installation |
No pit installing,easy to install and remove |
||||||||
|
Switches |
1.One control panel on the platform |
||||||||
Product Details
Advantages:
● Streamlined Structural Demands:
Our lift sidesteps the need for a dedicated machine room, requiring merely a solitary supportive wall for anchorage.
It flaunts a minimal pit depth necessity of merely 60mm, streamlining the installation process while being budget-friendly.
● Assured Safety and Dependence:
Our advanced hydraulic lift design negates the possibility of excessive speeding, thereby preventing abrupt ascending or descending.
A robust mechanical build coupled with steadfast installation grants remarkable safety margins.
Should there be an electrical outage or system fault, the integrated auxiliary power source facilitates a manual escape mechanism. One can simply engage the car's emergency interface to gradually redirect the hydraulic fluid to its reservoir, allowing a controlled and gentle return to the base level by gravity.
● Spatially Economic Configuration:
This elevator operates devoid of a counterbalance system, employing only a pair of guides, which markedly conserves spatial requirements.
Its slender blueprint affords it the versatility to be fitted within intricate or restricted spaces, proffering substantial flexibility for diverse building designs.
● Unobtrusive Functional Performance:
It's bestowed with an ultra-quiet pump station which employs variable frequency drives for noise minimization.
The utilization of a low-decibel hydraulic pump assures the lift's discreet presence, particularly in domestic environments.
● Enhanced Emergency Handling and Load Management:
The pump station is equipped with a manual lowering device, allowing occupants to descent and level the lift manually if a blackout occurs.
A built-in pressure relief mechanism serves as a safeguard against high pressure during ascents, embodying an overload safeguard feature to boost occupant protection.
Real Order
