Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of electric floor crane in China. We warmly welcome you to buy discount electric floor crane for sale here from our factory. Quality products and reasonable price are available.
The CATHAY Electric Floor cranes are perfect for lifting heavy objects in job shop settings, but there are always different and unique lifting requirements. CATHAY's latest CRANE rotatable main arm is designed with an automatic positioning device, which firmly locks the swivel arm to ensure customer safety.
Model Type | CSEC-1200 | CSEC-1200A | CSEC-700 | CSEC-900R |
Horizontal Reach | 1280+610+610mm | 1280+610+610mm | 1220+610+610mm | 1280mm+610mm+610mm |
Load Capacity | 1200kg | 1200kg(1280mm) | 700kg(1220mm) | 900kg(1280mm) |
Load Capacity (stage 1) | 600kg(1280~1890mm) | 600kg(1280~1890mm) | 400kg(1220~1830mm) | 450kg(1280~1890mm) |
Load Capacity (stage 2) | 300kg(1890~2500mm) | 300kg(1890~2500mm) | 200kg(1890~2440mm) | 250KG(1890~2500mm) |
Max Lifting Height | 3570mm | 3540mm | 3560mm | 3180mm |
Min Lifting Height | 960mm | 935mm | 950mm | 1410mm |
Retracted size(W*L*H) | 1920*760*1600mm | 1865*1490*1570mm | 2595*760*1580mm | 2000*1854*1550mm |
Arm Electric Rotation | / | / | / | 120°left/right |
Product Details
The batteries and battery charger are packed inside the battery pack. Follow the operating procedures to charge the battery:
1. Turn the switch key CCW to turn off the power supply.
2. Disconnect the battery cable connector from the compartment of the truck and then fully engaged it to the compartment of the battery charger.
3. Before connecting the battery charger to the local power supply, check and insure that the voltage of both is the same.
4. Connect the AC extension cord from the charger to the outlet of the local power supply. This will automatically turn the charger on, and it will run at a rate commensurate with the requirements of the batteries. The charger will automatically control the charging procedure and when the batteries are fully charged, the charger will only supply enough current to maintain the batteries' charge.
5. When the charging cycle is completed, disconnect the AC plug from the truck outlet and the power supply.
6. Remove the battery connector from the charger and fully engaged it to the drive plug.
