Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of electric scissor lift in China. We warmly welcome you to buy discount electric scissor lift for sale here from our factory. Quality products and reasonable price are available.
CATHAYLIFT Electric Scissor Lift adopts DC power supply, proportional control, can move freely and the moving speed can be adjusted, its strong power makes it have good climbing ability, and the product is installed with pothole protector, and the drive motor has automatic braking Function, emergency descent will be locked in case of failure, and it has self-diagnosis function, maintenance is very convenient, and the main components are world-class brands.
Model | CLSE6 | CLSE8 | |
Max.Platform Height | mm | 6000 | 8000 |
Max. Work Height | mm | 8000 | 10000 |
Max.Machine Height | mm | 7100 | 9100 |
Min.Platform Height | mm | 1010 | 1200 |
Ground Clearance | mm | 20 | 20 |
Lift Rated Capacity | kg | 300 | 300 |
Platform Extend Capacity | kg | 100 | 100 |
Platform Size | mm | 1880×900 | 1880×900 |
Platform Extend Length | mm | 900 | 900 |
Max.Drive Speed (platform Stowed) | km/h | 3~4 | 3~4 |
Max.Drive Speed (platform Elevated) | km/h | 0.6~1 | 0.6~1 |
Min.turning Radius | mm | 2000 | 2000 |
Max.Climbing Capacity | % | 10~15 | 10~15 |
Driving Wheel Size | mm | φ305×100 | φ305×100 |
Caster Size | in | φ305×100 | φ305×100 |
Driving Motor | v/kw | 2×24/0.5 | 2×24/0.5 |
Lifting Motor | v/kw | 24/2.2 | 24/2.2 |
Anerold battery | v/Ah | 2×12/150 | 2×12/150 |
Charger | V/A | 24/15 | 24/15 |
Pothole Protection System | Machine Control | Machine Control | |
Overall Size(L*W*H) | mm | 2050*900*2150 | 2050*900*2270 |
Overall Net Weight | kg | 1500 | 1700 |
Product Details:
Overview
Overview
Overview
Control Handle(Curties)
Ground Control Panel
Extendable Platform 900mm
Trojian Battery(America)
Hydraulic Pump Station (Switzerland Bucher Motor)
Smart Charger(Internal)
Buzzer, Tilt Sensor
Electric Steering(Stable And High Maneuverability)
Manually Release The Brake Button
Advantages:
● The product adopts imported intelligent control technology.
● Battery driven, low noise, no pollution, suitable for various working environments.
● A failure will limit the ascent of the platform.
● The drive motor has an automatic braking function.
● In the event of a malfunction emergency descent will be locked.
● Faults can be automatically diagnosed, and maintenance is very convenient.
● The main components are famous brands.
● Automatic pothole protection system, safer and more reliable.
● One-way extension platform, can quickly reach the operating point,
● The fault code is automatically displayed for easy maintenance.
Real Order:
